Tank Gauging

When liquids are stored in bulk quantities one of the more challenging aspects is simply knowing how much material is in your storage vessel (tank). Tank Gauging is the means by which the quantity inside the tank is established. Efficiently running a modern tank farm would be impossible without tank gauging. Our customers rely on our software to control inventories and manage their site operations, giving them safe and efficient bulk storage sites.

Launched in 1994 our tank gauge software VTW was one of the first to run on Windows with a graphical user interface. Our ethos is supporting our customers to allow them to get the most out of the equipment they have got while allowing them to choose the best new equipment for their needs regardless of the manufacturer.  Our tank gauging system, VTW, is scalable, customisable and compatible with major vendors’ level gauges; including Honeywell Enraf, Emerson/Saab, VarecWhessoe and Endress+Hauser. Supporting sites of up to 1,500 tanks.

With over 600 installations worldwide, our customers vary from independent bulk liquid storage companies to refineries, to networks of manned and unmanned oil depots. VTW Tank Gauging Software gives operators the tools they need to ensure the safe storage and movement of products, whilst optimising the use of tank capacity and improving efficiency.

benefits

Safety
Our software's innovative tank overview gives you instant access to accurate and secure inventory data, reducing the risk of overfill and leaks by alarming operators to act quickly before a hazard occurs. Preventing injuries, significant damage to assets and environmental harm.
Cost Saving
Our solutions can extend the life of tank gauges and other equipment. Our gauge Emulators allow different vendor's gauges to work together on the same data lines. No need to replace expensive equipment.
Flexibility
Our software and hardware allows you to integrate devices from different suppliers, avoiding vendor locking.
24-7 access
Remotely monitor stock 24-7 across all of our sites, either from the office or at home with our new Business Information Server. This is particularly useful in unmanned sites, giving you both visibility and peace of mind.
Reliability
Receive reliable, accurate and instant data from all your tank farm simultaneously. Resulting in improved efficiency and huge cost savings.
Inventory Management
Tank Gauging is essential to determine the inventory of liquid bulk storage tanks.
Tank Gauging Software
vtw

VTW has undergone a process of continual innovation over 25 years, often incorporating feedback and requests from customers across the world. All our software is designed, developed, and tested in-house by a team of bulk liquid storage and handling experts. One of the great advantages MHT has is that we can be flexible and adapt to meet the requirements of different sites. The latest version of VTW includes the core features of a homepage overview and grid view, data trending, movements, security and data integrity, SCADA screens, alarm/event viewer, audit trails, and the new Business Information Server.



  • Supports sites of up to 1,500 tanks.
  • Windows 10 / Windows Server 2019 compatible.
  • Real-Time and Historical Data.
  • Redundant Systems.
  • Alarm Management to improve safety.
  • Movements package.
  • Real-Time and historical data.
  • Reports on Demand.
  • SCADA Designer
  • Business Information Server
  • RMS2 – radio annunciation
  • HM21 Inventory Calculations
lng Software
Lms

Our software for LNG offers a total LNG Tank Storage and management solution for peak shaving, receiving and production LNG Facilities. The LMS system has been designed to interface to all instruments commonly found on LNG storage tanks, and to collect and present the instrument data through a range of intuitive graphical user interfaces. The software can be used alongside our hardware; Field Display, Mini Reciever and Temperature Multiplexer.

  • Tank Gauging system for Liquefied Natural Gas (LNG).
  • Windows 10 / Windows Server 2019 compatible.
  • Can operate in a simple standalone configuration or as a fully redundant system.
  • The LMS system has a flexible and scalable architecture allowing it to be tailored to a number of different applications easily.
  • Summarises data from Mini Receiver, host systems, and other 3rd party field gateways.
  • Use alongside the Field Display and Temperature Multiplexer for a full LNG management solution.
  • Uses industry-standard calculations.
  • Rollover Prediction module available.
  • Live data.
  • Redundancy on the measurement of level
    and temperature.
  • Real-time and historical trending.
  • Alarm management and Annunciation.
  • Instrument support.
  • LNG rollover Predication model (Optional).

hardware

Gauge Emulator
  • Allows seamless integration of tank gauges from different vendors into existing system infrastructure.
  • Ability to convert most vendor protocols releasing any obligation to use only one supplier.
  • Compatible with most popular gauge manufacturers such as Emerson, Honeywell Enraf, Endress+Hauser, etc.
  • ATEX/IECEx hazardous area Zone 1 certified.
Mini Receiver
  • A smartly compact tank gauging and tank inventory management
    system.
  • Consolidates devices from multiple vendors into a single unit for cost-effective bulk liquid storage.
  • Allows for step-by-step upgrade due to integration of legacy devices.
  • Optional touchscreen display.
Field Display
  • Tank side monitor providing live consolidation of data from different vendor instruments.
  • Compatible with most popular gauge manufacturers such as Emerson, Honeywell Enraf and Endress+Hauser.
  • Graphical display with magnetic key for menu navigation.
  • ATEX/IECEx hazardous area Zone 1 certified.
Remote I/o
  • Local or remote field data acquisition system.
  • Reads sensor data making it available to host systems via single/dual digital Fieldbus technology.
  • Up to 6 sensor inputs, either 4-20mA or HART.
  • ATEX hazardous area Zone 1 certified, safe area version available.
TEMPERATURE MULTIPLEXER
  • Multi-spot temperature transmitter capable of accepting up to 16 RTD inputs.
  • Larger numbers of RTDs can be accommodated by multi-dropping onto the same Fieldbus.
  • Performs measurements locally, reducing the amount of expensive cabling required.
  • ATEX hazardous area Zone 1 certified.
RMS2
  • RMS2 integrates with the VTW Tank Gauging System to automatically announce alarms over a site radio system.
  • requires an Ethernet connection to the tank gauging system and
    connection to a radio base station.
  • Virtualisation and high availability.
  • Interfaces with VTW for real-time physical stock data.
  • Fail-safe component.
Discover more

DATASHEETS

VTW Tank Gauging Software 18.3.1

With over 600 installations worldwide VTW is a scalable tank gauging and inventory management solution designed to adapt to any site requirement regardless of size or budget.

mini receiver

The Mini receiver is a smartly compact tank gauging and tank inventory management system that consolidates devices from multiple vendors into a single unit for cost-effective bulk liquid storage.

rms2

MHT Technology Ltd’s new radio messaging system ‘RMS2’ was launched in March 2020, enabling digital tank gauging systems to send timely warning notifications using existing radio systems.

What is tank gauging?

When liquids are stored in bulk quantities one of the more challenging aspects is simply knowing how much material is in your storage vessel (tank). Tank Gauging is the means by which the quantity inside the tank is established.

How does a tank gauging system work?

At its simplest, a manual dipstick is used to measure the level of liquid inside the tank. Having determined the level in the tank you can calculate the volume of liquid in the tank that would result in this level and the volume of space in the tank (ullage) that could be filled with liquid. A tank gauging system just automates this process by using an electronic level gauge to determine the level in the tank and a computer to calculate the volumes. By monitoring the changes in level the computer can also determine flow rates in and out of the tank, and issue alarms should the tank be in danger of being overfilled.

What is a gauging system?

Gauging systems are used to estimate or gauge a quantity. For example, the amount of oil stored in a tank can be gauged by measuring the depth of oil inside the tank and mathematically estimating a volume to correspond to that measurement.
